AM FM Stereo Receiver KR-9600

AM FM Stereo Receiver KR-9600; Trio-Kenwood (ID = 2505173) Radio AM FM Stereo Receiver KR-9600; Trio-Kenwood (ID = 2505174) Radio
AM FM Stereo Receiver KR-9600; Trio-Kenwood (ID = 2505175) Radio AM FM Stereo Receiver KR-9600; Trio-Kenwood (ID = 2505176) Radio
AM FM Stereo Receiver KR-9600; Trio-Kenwood (ID = 573428) Radio AM FM Stereo Receiver KR-9600; Trio-Kenwood (ID = 643270) Radio
Use red slider bar for more.
AM FM Stereo Receiver KR-9600; Trio-Kenwood (ID = 2505173) Radio
Trio-Kenwood: AM FM Stereo Receiver KR-9600 [Radio] ID = 2505173 1400x450
Select picture or schematic to display from thumbnails on the right and click for download.
For model AM FM Stereo Receiver KR-9600, Trio-Kenwood Electronic Inc.; Komagane:
Ebay.com auction item_223848603770 seller garydolson

Country:  Japan
Manufacturer / Brand:  Trio-Kenwood Electronic Inc.; Komagane
alternative name

Trio Corp.
Brand
Jennen
Year: 1978 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 320 W (unknown quality)
from Radiomuseum.org Model: AM FM Stereo Receiver KR-9600 - Trio-Kenwood Electronic Inc.;
Material Metal case
Shape Rack
Dimensions (WHD) 22.9 x 6.4 x 16.5 inch / 582 x 163 x 419 mm
Notes AM/FM Stereo Receiver with 160 watts per channel driven at 8 ohms.
2 selectable-range Power Meters..
Separate equalizer amplifiers for Phono 1 and Phono 2.
FM Dolby deemphasis switch.
Optional CB-15 walnut veneer cabinet available.
Net weight (2.2 lb = 1 kg) 26.5 kg / 58 lb 5.9 oz (58.37 lb)
Source of data -- Original prospect or advert

Model page created by Franz Scharner. See "Data change" for further contributors.
