H17T245 Ch= V-2373

H17T245 Ch= V-2373; Westinghouse El. & (ID = 2471682) Television
Use red slider bar for more.
H17T245 Ch= V-2373; Westinghouse El. & (ID = 2471682) Television
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Westinghouse El. & Mfg. Co. - see also Canadian W.
alternative name

Westinghouse El. Int.
Year: 1957 ? Category: Television Receiver (TV) or Monitor
Valves / Tubes 15: 3BN4 6CG8A 8AU8 6BN4 6AQ5A 4BZ6 4BZ6 4CB6 4CS6 8CS7 8CG7 17DQ6A 17D4 1X2B 17CDP4
Main principle Superhet with RF-stage
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: H17T245 Ch= V-2373 - Westinghouse El. & Mfg. Co. -
Notes

Westinghouse model H17T245 is a 17" b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with chassis V-2373 and picture tube 17CDP4.



Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 378 Folder 14-S dated 11-57)

Model page created by Dirk Taekels. See "Data change" for further contributors.
