4/3/2 Channel Power Amplifier YPA-1020
Yamaha Co.; Hamamatsu
- Country
- Japan
- Manufacturer / Brand
- Yamaha Co.; Hamamatsu
- Year
- 1991
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 207840
-
- alternative name: Nippon Gakki
Service Manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 10-16 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 300 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: 4/3/2 Channel Power Amplifier YPA-1020 - Yamaha Co.; Hamamatsu
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 300 x 55 x 327 mm / 11.8 x 2.2 x 12.9 inch
- Notes
- Car HiFi Endstufe. 4-Kanal Verstärker mit 4x 60W Sinus an 4 Ohm, umschaltbar auf 3-Kanal Betrieb 60+60+150W oder 2-Kanäle gebrückt 2x 150W, Stromversorgung 12V, Absicherung: 1x 3A 2x 30A.
- Net weight (2.2 lb = 1 kg)
- 4.7 kg / 10 lb 5.6 oz (10.352 lb)
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by a member from D. See "Data change" for further contributors.
