- Country
- United States of America (USA)
- Manufacturer / Brand
- Air King Products Co.; Brooklyn (NY)
- Year
- 1950
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 114384
Sams Photofact Set 91 Folder 2 Date 4-50
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 31
- Valves / Tubes
- 6J6 6J6 6J6 6BA6 6BA6 6AU6 6AL5 6AT6 6K6GT 6AG5 6AG5 6AG5 6AG5 6AL5 6AU6 6K6GT 6SK7 6SH7 6SN7GT 6J5 6K6GT 6AL5 6K6GT 6AC7 6BG6G 6K6GT 1B3GT 5Y4G 5U4G 5U4G 16AP4
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 110 - 120 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: A1016 - Air King Products Co.;
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
31 tubes incl. picture tube: RF 6J6 6J6 6J6 - sound 6BA6 6BA6 6AU6 6AL5 6AT6 6K6GT - video 6AG5 6AG5 6AG5 6AG5 6AL5 6AU6 6K6GT - sync. amp. 6SK7 6SH7 6SN7GT - vert. 6J5 6K6GT - horiz. 6AL5 6K6GT 6AC7 6BG6G - 6K6GT 1B3GT 5Y4G - power 5U4G 5U4G in parallel, picture tube 16AP4.
- Mentioned in
- Photofact Folder, Howard W. SAMS (Sams Photofact Set 91 Folder 2 Date 4-50)
- Author
- Model page created by Peter Hoddow. See "Data change" for further contributors.
- Other Models
-
Here you find 293 models, 145 with images and 240 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Air King Products Co.; Brooklyn (NY)
