HiFi Lautsprecher-Box TS100

Arcus Elektroakustik GmbH; Berlin

Data
Forum
Pictures
Collections

  • Year
  • 1988 ??
  • Category
  • Loudspeaker, headphone or earphone
  • Radiomuseum.org ID
  • 261192

 Technical Specifications

  • Wave bands
  • - without
  • Details
  • Hi-Fi equipment
  • Power type and voltage
  • No Power needed
  • Loudspeaker
  • 3 Loudspeakers
  • Power out
  • 60 W (100 W max.)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: HiFi Lautsprecher-Box TS100 - Arcus Elektroakustik GmbH;
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 230 x 350 x 260 mm / 9.1 x 13.8 x 10.2 inch
  • Notes

  • 3-Wege-Bassreflex Box

    • Tieftöner: 160 mm
    • Mitteltöner: 65 mm
    • Hochtöner: 25 mm Kalotte

    Cross-over 800 & 3000 Hz.
    Frequency response: 42 - 25.000 Hz.
    Impedanz: 4 Ω.
    Nennbelastbarkeit: 60 Watt.
    Musikbelastbarkeit: 100 Watt.
    Made in Germany. Berlin-West.

  • Net weight (2.2 lb = 1 kg)
  • 6 kg / 13 lb 3.5 oz (13.216 lb)
  • Price in first year of sale
  • 300.00 DM
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
