• Year
  • 1937
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 201036
    • Brand: Alba

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 117.5 kHz
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 190-250 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 815 [AC] - Alba Brand Balcombe Ltd., ALBA
  • Shape
  • Tablemodel, high profile (upright - NOT Cathedral nor decorative).
  • Notes
  • The chassis is identical to that fitted to the Alba 615 AC armchair console and 650 AC console and similar to that in the 910 AC radiogram.
    There are AC/DC versions of all these models.



  • Author
  • Model page created by Howard Craven. See "Data change" for further contributors.
