RX Meter 250-A

RX Meter 250-A; Boonton Radio Corp.; (ID = 1247633) Equipment

RX Meter 250-A; Boonton Radio Corp.; (ID = 1247634) Equipment
RX Meter 250-A; Boonton Radio Corp.; (ID = 1106050) Equipment RX Meter 250-A; Boonton Radio Corp.; (ID = 1106051) Equipment
RX Meter 250-A; Boonton Radio Corp.; (ID = 1106052) Equipment RX Meter 250-A; Boonton Radio Corp.; (ID = 1248042) Equipment
Use red slider bar for more.
RX Meter 250-A; Boonton Radio Corp.; (ID = 1106050) Equipment
Boonton Radio Corp.;: RX Meter 250-A [Equipment] ID = 1106050 920x634
Select picture or schematic to display from thumbnails on the right and click for download.
For model RX Meter 250-A, Boonton Radio Corp.; Boonton, New Jersey:
USA_Boonton Radio Corp_RX meter 250A

Country:  United States of America (USA)
Manufacturer / Brand:  Boonton Radio Corp.; Boonton, New Jersey
Year: 1954 ?? Type: Service- or Lab Equipment
Valves / Tubes 8: 5718 5Y3 6AB4 6AG5 6H6 0D3
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker
Power out
from Radiomuseum.org Model: RX Meter 250-A - Boonton Radio Corp.; Boonton,
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 20 x 10 x 12 inch / 508 x 254 x 305 mm
Notes RF bridge; internal generator covering from 500KHz to 250MHz in six bands. Schering bridge, to measure resistance, capacitance and inductance.
The RX MeterType 250-A is a wide frequency range Impedance Meter designed to permit accurate individual determination of the equivalent parallel resistance and parallel reactance of two-terminal networks and components. The instrument is completely self-contained and consists fundamentally, of a refined Schering bridge circuit, together with its associated oscillator, detector, amplifier, null detector and power supply. Bridge balance is obtained by means of two calibrated dials which indicate, respectively, parallel resistance and parallel capacitance of the unknown.
Net weight (2.2 lb = 1 kg) 40 lb 0 oz (40 lb) / 18.160 kg
Price in first year of sale 1,250.00 $
Literature/Schematics (1) Electronics, November 1954
