Cathode-Ray Oscillograph 274A

Cathode-Ray Oscillograph 274A; DuMont Labs, Allen B (ID = 1646170) Equipment Cathode-Ray Oscillograph 274A; DuMont Labs, Allen B (ID = 880954) Equipment
Cathode-Ray Oscillograph 274A; DuMont Labs, Allen B (ID = 880953) Equipment Cathode-Ray Oscillograph 274A; DuMont Labs, Allen B (ID = 1646171) Equipment
Cathode-Ray Oscillograph 274A; DuMont Labs, Allen B (ID = 1646172) Equipment Cathode-Ray Oscillograph 274A; DuMont Labs, Allen B (ID = 1646173) Equipment
Use red slider bar for more.
Cathode-Ray Oscillograph 274A; DuMont Labs, Allen B (ID = 1646170) Equipment
DuMont Labs, Allen B: Cathode-Ray Oscillograph 274A [Equipment] ID = 1646170 933x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model Cathode-Ray Oscillograph 274A, DuMont Labs, Allen B., Inc.

Country:  United States of America (USA)
Manufacturer / Brand:  DuMont Labs, Allen B., Inc.
alternative name

Dumont Television & Radio
Year: 1949 Type: Service- or Lab Equipment
Valves / Tubes 6: 6AC7 6AC7 884 80 80 5BP1
schematic requested
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 115/230 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Cathode-Ray Oscillograph 274A - DuMont Labs, Allen B., Inc.
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 218 x 356 x 502 mm / 8.6 x 14 x 19.8 inch
Net weight (2.2 lb = 1 kg) 15.9 kg / 35 lb 0.4 oz (35.022 lb)
Collectors' prices

Model page created by Louis Morrell. See "Data change" for further contributors.

All listed radios etc. from DuMont Labs, Allen B., Inc.
Here you find 194 models, 91 with images and 155 with schematics.
