358X; Eddystone, (ID = 849661) Receiver-C

358X; Eddystone, (ID = 849662) Receiver-C

358X; Eddystone, (ID = 849663) Receiver-C

358X; Eddystone, (ID = 849664) Receiver-C

358X; Eddystone, (ID = 849665) Receiver-C

358X; Eddystone, (ID = 849667) Receiver-C

358X; Eddystone, (ID = 849668) Receiver-C

358X; Eddystone, (ID = 849669) Receiver-C

358X; Eddystone, (ID = 849670) Receiver-C

358X; Eddystone, (ID = 849671) Receiver-C
358X; Eddystone, (ID = 849731) Receiver-C
Use red slider bar for more.
358X; Eddystone, (ID = 849731) Receiver-C
Eddystone,: 358X [Receiver-C] ID = 849731 739x535
Select picture or schematic to display from thumbnails on the right and click for download.
For model 358X, Eddystone, Birmingham:
Original manual

Country:  Great Britain (UK)
Manufacturer / Brand:  Eddystone, Birmingham
alternative name

Stratton & Co.Ltd.; Birmingham
Year: 1940 Category: Commercial Receiver (may include amateur bands)
Valves / Tubes 8: EF39 ECH35 EF39 EF39 EBC33 EF39 EL32 5Z4G
Main principle Superhet with RF-stage; ZF/IF 450 kHz
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker - For headphones or amp.
Power out 1.5 W (unknown quality)
from Radiomuseum.org Model: 358X - Eddystone, Birmingham
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 20.5 x 12 x 13.5 inch / 521 x 305 x 343 mm
Notes Coverage 40 kHz - 31 MHz in 10 bands. Wave band is changed by plugging in different coil units.
Integrated crystal filter, note the "Xtal Control" switch left of "Tone" and "BFO" controls (see 358 for model without crystal filter).
Matching external Power supply S390 supplying 6 V LT and 175/180 V HT or S390B (different dimensions).
Army tube designations: ARP34 ARTH2 ARP34 ARP34 AR21 ARP34 VT52 ZA3489.
Navy designation Receiver B34.
Net weight (2.2 lb = 1 kg) 22.9 kg / 50 lb 7 oz (50.441 lb)
Collectors' prices
Mentioned in Wireless for the Warrior Vol.3
