RF Signal Generator Kit 330

RF Signal Generator Kit 330; EICO Electronic (ID = 1677476) Equipment RF Signal Generator Kit 330; EICO Electronic (ID = 1318013) Equipment
RF Signal Generator Kit 330; EICO Electronic (ID = 1677474) Equipment RF Signal Generator Kit 330; EICO Electronic (ID = 1677475) Equipment
RF Signal Generator Kit 330; EICO Electronic (ID = 1677698) Equipment
Use red slider bar for more.
RF Signal Generator Kit 330; EICO Electronic (ID = 1677476) Equipment
EICO Electronic: RF Signal Generator Kit 330 [Equipment] ID = 1677476 933x962
Select picture or schematic to display from thumbnails on the right and click for download.
For model RF Signal Generator Kit 330, EICO (Electronic Instrument Co.Inc.) Brooklyn

Country:  United States of America (USA)
Manufacturer / Brand:  EICO (Electronic Instrument Co.Inc.) Brooklyn
Year: 1975 ?? Type: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: RF Signal Generator Kit 330 - EICO Electronic Instrument Co.
Material Metal case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 7.5 x 8.5 x 5 inch / 191 x 216 x 127 mm
Notes Covers 100 kHz to 54 MHz in five bands, internal audio oscillator for modulation, external modulation also possible, BNC connectors.
Source of data -- Collector info (Sammler)

Model page created by a member from A. See "Data change" for further contributors.
