T-3535

• Country
• Denmark

• Manufacturer / Brand
• Fabrikken 3-F, Horsens

• Year
• 1978 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 121736

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 63

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 200; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 80 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: T-3535 - Fabrikken 3-F, Horsens

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 450 x 93 x 290 mm / 17.7 x 3.7 x 11.4 inch

• Notes
• ICs: 9
  Stereo-Tuner/Verstärker mit roter LED-Senderskala; 2× 35 Watt (Sinus) an 4 Ω; 2 Lautsprecherpaare schaltbar; 7 elektronische Berührungstipptasten mit roter LED-Funktionsanzeige; Tunoscope mit 3-fach LED-Anzeige + MPX + Stereo LED; Eingänge: Phono, Tape (DIN).
  Hungarian solicited, Tungsram brand is also available.

• Net weight (2.2 lb = 1 kg)
• 8 kg / 17 lb 9.9 oz (17.621 lb)

• Price in first year of sale
• 16,000.00 HUF

• Source of data
• - - Data from my own collection

• Literature/Schematics (1)
• Sztereo radiok szervizkönyve II.,Kókai-Varsányi, Bp. 1982

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.

• Other Models

• Here you find 2 models, 2 with images and 1 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Fabrikken 3-F, Horsens
