• Country
• United States of America (USA)

• Manufacturer / Brand
• Fisher Radio; New York (NY)

• Year
• 1977

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 148006

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Other Combination - see Notes

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 100 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: HiFi Music Center MCE4025 - Fisher Radio; New York NY

• Shape
• Tablemodel, with any shape - general.

• Notes
• Stereo-Music-Center bestehend aus:
  4-Band-Tuner mit AFC, 7 Sensortasten.
  Verstärker mit 100 Watt Musik, Muting, Loudness, DIN-Anschlüsse.
  Cassettendeck mit Dolby, 3-Bandsortenwahlschalter, Memory.
  Plattenspieler riemengetrieben, 33 und 45 UpM, Antiskating, magnetisches Tonabnehmersystem.
  3-Weg-Boxen (Holzgehäuse schwarz).

• Source of data
• -- Original prospect or advert

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
