DHS66 (Stein DHS66)

DHS66 ; Funktechnik Leipzig, (ID = 342729) Speaker-P
DHS66 ; Funktechnik Leipzig, (ID = 342728) Speaker-P DHS66 ; Funktechnik Leipzig, (ID = 342878) Speaker-P
DHS66 ; Funktechnik Leipzig, (ID = 530603) Speaker-P DHS66 ; Funktechnik Leipzig, (ID = 530607) Speaker-P
DHS66 ; Funktechnik Leipzig, (ID = 530608) Speaker-P
DHS66 ; Funktechnik Leipzig, (ID = 342728) Speaker-P
Funktechnik Leipzig,: DHS66 [Speaker-P] ID = 342728 822x668
For model DHS66 (Stein DHS66), Funktechnik Leipzig, PGH; Leipzig

Country:  Germany
Manufacturer/Brand:  Funktechnik Leipzig, PGH; Leipzig
Brand
Stein
Year: 1969 Type: Loudspeaker (speaker or headphone)
Details
Power type and voltage No Power needed
Loudspeaker
Power out
from Radiomuseum.org Model: DHS66 - Funktechnik Leipzig, PGH;
Material Various materials
Shape Miscellaneous shapes - described under notes.
Notes Dynamischer Kopfhörer, 200 Ohm Scheinwiderstand, 20...15000 Hz, 90 mW; Mikrofon 200 Ohm, 200...15000 Hz, nierenförmig für Nahbesprechung. Anschluss gemeinsam über 5-pol. Diodenstecker. Die Schallwandler tragen den Schriftzug "Stein". Die Sprechgarnitur wurde später auch vom VEB Elektroakustik Leipzig produziert.
Net weight (2.2 lb = 1 kg) 0.2 kg / 0 lb 7 oz (0.441 lb)
Price in first year of sale 225 Mark
Source of data Radiokatalog Band 2, Ernst Erb
Mentioned in -- Original-Prospect

Model page created by Wolfgang Eckardt. See "Data change" for further contributors.

All listed radios etc. from Funktechnik Leipzig, PGH; Leipzig
Here you find 16 models, 16 with images and 4 with schematics.
