G57R


Country: Italy Manufacturer/Brand: Geloso SA; Milano
Year: 1939 Type: Radio or TunerBroadcast receiver (Radio).
Im Gegensatz zu Radioempfängern für kommerzielle und/oder militärische Zwecke und den frühen Empfängern für Morsezwecke nennen wir hier Radio bzw. Rundfunkempfänger. Aber: Gemäss internationaler Sprachregelung führt der Radiokatalog Band 1 alle Empfänger mit aktiven Bauteilen als RADIO. Wir unterscheiden hier ebenfalls nicht, ob mit Röhren bestückt, hybrid, mit Transistoren oder/und ICs.
Mod.-ID = 18009 previous | Result List | next | New search for Radios etc. Schematics etc.: 1 (for members) Principle Super-Heterodyne (Super in general); IF-Freq. 467 kHzSuperhet - normally without a preamplification stage (as far as known). Please use «To add informations to model» if you know more! Thanks.
Récepteur TSF superhétérodyne. Normalement sans préamplification de HF.
Superhet ohne Vorstufe.
Nicht immer war bei der Erfassung klar, ob der Empfänger eine Vorstufe aufweist oder nicht. Im Zweifelsfall kam das Gerät in diese Kategorie.

Wave bands Broadcast and Short Wave (SW).
Power type and voltage Alternating Current supply (AC) / 110, 125, 140, 160, 220 VoltAC set plus voltage range.
/ = 2 different voltages
- = voltage from-to
* = «Special»
Apparareil à courant alternatif. Tensions mentionnées.
/ = 2 Spannungswahlen
- = von-bis
* = Fabrikwahl/«Spezial»
Normalerweise sind diese Geräte mit einem Trafo mit Primär- und Sekundärwicklungen versehen. Dadurch führt das Chassis kein gefährliches Potential.

Loudspeaker/pwr.out Electro Magnetic Dynamic LS (moving-coil with field excitation coil)Electro magnetic dynamic loudspeaker (moving-coil principle by Rice-Kellog) with field excitation coil - mostly used as choke.
Haut parleur dynamique avec bobine d`excitation - plus souvent aussi utilisé pour le self.
Elektrodynamischer Lautsprecher mit Erregerspule für das Magnetfeld (Fremderregung), meist gleichzeitig als Siebglied dienend.

www.radiomuseum.org Model: G57R Material Wooden caseWooden case. Most radios have a wooden cabinet until the WW2. Caisse en bois.
Die meisten Heim-Rundfunkempfänger führen von Beginn an bis etwa Ende 60er Jahre Holz als Gehäuse. Auch frühe Reiseempfänger zeigen Holz (speziell in den 20er Jahren) oder Holz mit Stoffüberzug etc.

Shape Miscellaneous shapes - described under notes.
Valves / Tubes 5: 6A8G     (more for members)
Notes Il G57R (come il G50R e il G55R) poteva utilizzare i mobili in noce nr 3040 (andamento orizzontale), nr 3011 (verticale) e 3706 (console con giradischi).
External source of data E. Erb 3-907007-36-0
Source of data Guida Pratica Antique Radio IIGuida Pratica Antique Radio II, 2000, Mosè Edizioni, Maser, Italia.
Circuit diagram reference Die «Thali Schemasammlung» führt das Modell.Schweiz: Thali Schemasammlung (lose Blätter mit schwarzen Ordnern) der 30er- bis Anfang 50er Jahre.Einige Sammler besitzen diese Schaltplansammlung vollständig, andere Teile davon. Hier im virtuellen Museum sollten Sie alle Geräte aus Thali finden, also auch Importgeräte.Die Sammlung ist bei Thali seit vielen Jahren nicht mehr erhältlich.



Further information on

G57R (Geloso SA; Milano)

geloso: G57R;   (19.09.2005)  Enrico BonisoloHits: 457     Replies: 0 Geloso G57R: ricevitore supereterodina a 5 valvole OCTAL serie americana 6A8 6K7 6Q7 6V6 5Y3, soprammobile di grandi dimensioni. Alimentazione AC con cambiotensioni 110-125-140-160-220 V 42-60 Hz. Altoparlante elettrodinamico (con bobina di campo) di generose dimensioni. E' stato prodotto con differenti gruppi ad alta frequenza per differenti gamme d'onda: il tipo più comune presenta le onde medie + 3 gamme ad onde corte. Questa radio progettata sul finire degli anni'30 è stata ispiratrice di moltissime radio artigianali o semiartigianali prodotte poi nel dopoguerra in Italia da piccole ditte o artigiani, fino ai primi anni '50, usando a volte un mix di valvole europee e americane, od anche residuati bellici, tipo la VT86 (6K7) e simili.  Telai e parti staccate per apparecchi simili (la disposizione dei componenti sul telaio era identica!) sono stati prodotti per anni da svariate ditte. Telai di questo genere sono stati usati anche per moltissimi radiogrammofoni anni '50, i cosiddetti "fonobar" per il fatto che presentavano anche vani dove era possibile riporre bottiglie di liquori; generalmente questi vani all'interno erano rivestiti di specchietti secondo la moda del tempo.
