DC Oscilloscope OR-1

DC Oscilloscope OR-1; Heathkit Brand, (ID = 711067) Equipment

DC Oscilloscope OR-1; Heathkit Brand, (ID = 711068) Equipment
DC Oscilloscope OR-1; Heathkit Brand, (ID = 691348) Equipment DC Oscilloscope OR-1; Heathkit Brand, (ID = 691349) Equipment
DC Oscilloscope OR-1; Heathkit Brand, (ID = 691350) Equipment
Use red slider bar for more.
DC Oscilloscope OR-1; Heathkit Brand, (ID = 691348) Equipment
Heathkit Brand,: DC Oscilloscope OR-1 [Equipment] ID = 691348 426x420
Select picture or schematic to display from thumbnails on the right and click for download.
For model DC Oscilloscope OR-1, Heathkit (Brand), Heath Co.; Benton Harbor (MI):
From manual

Country:  United States of America (USA)
Manufacturer / Brand:  Heathkit (Brand), Heath Co.; Benton Harbor (MI)
alternative name

Heath Company
Year: 1960 ?? Category: Service- or Lab Equipment
Valves / Tubes 12: 6C4 6BQ7 12AU7 12AT7 0A2 0B2 1V2 5ADP2
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 105/125 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: DC Oscilloscope OR-1 - Heathkit Brand, Heath Co.;
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 11 x 6 x 20 inch / 279 x 152 x 508 mm
Notes X&Y channels identical-bandwidth DC to 200Hz-sensitivity. 1v per cm/input impedance 3.6 Megaohm.
Net weight (2.2 lb = 1 kg) 17 lb 5 oz (17.313 lb) / 7.860 kg
