• Country
• United States of America (USA)

• Manufacturer / Brand
• Heathkit (Brand), Heath Co.; Benton Harbor (MI)

• Year
• 1964–1969

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 97377

• • alternative name: Heath Company

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• 6EU7 6EU7 6EU7 ECL86 ECL86 ECL86 ECL86

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 20 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Stereo Amplifier AA-32E - Heathkit Brand, Heath Co.;

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 330 x 120 x 240 mm / 13 x 4.7 x 9.4 inch

• Notes
• Magn. und keramischer Tonabnehmer-Eingang. E-Modell = auch 220 Volt. 2 x 10W Musikleistung. Preis gilt für Bausatz.

• Net weight (2.2 lb = 1 kg)
• 7.2 kg / 15 lb 13.7 oz (15.859 lb)

• Price in first year of sale
• 229.00 DM

• Source of data
• -- Original prospect or advert

• Mentioned in
• Heathkit-Katalog, Sommer 1967

• Literature/Schematics (1)
• Funk-Technik (FT) (10/1964, S. 377 / Werbeanzeige)

• Author
• Model page created by Trev Levick. See "Data change" for further contributors.
