For model 534, Irish Electrical Co. Ltd., (IEC) Dundrum, Dublin:
Front View

Country:  Ireland
Manufacturer / Brand:  Irish Electrical Co. Ltd., (IEC) Dundrum, Dublin
Year: 1959 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: UCH81 UBF89 UCL83
schematic requested
Main principle Super-Heterodyne (Super in general); ZF/IF 400 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 200-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 15 cm = 5.9 inch
Power out
from Radiomuseum.org Model: 534 - Irish Electrical Co. Ltd., IEC
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 310 x 200 x 140 mm / 12.2 x 7.9 x 5.5 inch
Notes One Rectifier
Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)
Source of data - - Data from my own collection

Model page created by Carlos Alves. See "Data change" for further contributors.
