• Year
  • 1969
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 226820

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 7
  • Main principle
  • Superheterodyne (common); ZF/IF 470 kHz
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Dry Batteries / 4 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Power out
  • 0.45 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: KR611 - ITT-KB; Foots Cray, Kent; ITT
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 8.6 x 4.75 x 2.5 inch / 218 x 121 x 64 mm
  • Notes
  • Socket for earphone. Elliptical loudspeaker 5 x 3 inch. Tone control switch.

    Similar to model RGD R125.

    Made in Japan for ITT-KB.

  • Net weight (2.2 lb = 1 kg)
  • 2 lb 4 oz (2.25 lb) / 1.022 kg
  • Price in first year of sale
  • 10.95 UK £
  • Mentioned in
  • Radio! Radio! (Date and price from Radio Radio, (Hill), page 260)
  • Literature/Schematics (1)
  • ERT Service Chart 1799
  • Author
  • Model page created by Howard Craven. See "Data change" for further contributors.
