UN6-100

UN6-100 ; Philco, Philadelphia (ID = 98986) Car Radio

UN6-100 ; Philco, Philadelphia (ID = 352974) Car Radio

UN6-100 ; Philco, Philadelphia (ID = 352975) Car Radio

UN6-100 ; Philco, Philadelphia (ID = 352976) Car Radio

UN6-100 ; Philco, Philadelphia (ID = 352977) Car Radio

UN6-100 ; Philco, Philadelphia (ID = 352978) Car Radio

UN6-100 ; Philco, Philadelphia (ID = 352979) Car Radio

UN6-100 ; Philco, Philadelphia (ID = 352980) Car Radio

UN6-100 ; Philco, Philadelphia (ID = 836026) Car Radio

UN6-100 ; Philco, Philadelphia (ID = 836027) Car Radio
UN6-100 ; Philco, Philadelphia (ID = 836025) Car Radio UN6-100 ; Philco, Philadelphia (ID = 352973) Car Radio
UN6-100 ; Philco, Philadelphia (ID = 1013236) Car Radio UN6-100 ; Philco, Philadelphia (ID = 1013799) Car Radio
UN6-100 ; Philco, Philadelphia (ID = 1013800) Car Radio
Use red slider bar for more.
UN6-100 ; Philco, Philadelphia (ID = 836025) Car Radio
Philco, Philadelphia: UN6-100 [Car Radio] ID = 836025 933x682
Select picture or schematic to display from thumbnails on the right and click for download.
For model UN6-100, Philco, Philadelphia Stg. Batt. Co.; USA:
SAMS Photofact

Country:  United States of America (USA)
Manufacturer / Brand:  Philco, Philadelphia Stg. Batt. Co.; USA
Year: 1949 Type: Car Radio
Valves / Tubes 6: 7A7 7B8 7A7 7B6 7A5 7Y4
Principle Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: UN6-100 - Philco, Philadelphia Stg. Batt
Material Metal case
Shape Chassis only or for «building in»
Notes Vibrator for +B.
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 18 = 1949 and before
Literature/Schematics (1) Beitman Radio Diagrams, Vol. 09, 1949

All listed radios etc. from Philco, Philadelphia Stg. Batt. Co.; USA
