LS412UB (LS 412 UB)

Image ID = 318480 for Philips, Svenska AB, LS412UB Image ID = 318482 for Philips, Svenska AB, LS412UB
Image ID = 318481 for Philips, Svenska AB, LS412UB Image ID = 702905 for Philips, Svenska AB, LS412UB
Image ID = 702906 for Philips, Svenska AB, LS412UB Image ID = 702907 for Philips, Svenska AB, LS412UB
Image ID = 702908 for Philips, Svenska AB, LS412UB
Image ID = 318480 for Philips, Svenska AB, LS412UB
Philips, Svenska AB,: LS412UB [Radio] ID = 318480 621x439

Country: Sweden Manufacturer/Brand: Philips, Svenska AB, Stockholm
Year: 1955 ?? Type: Radio or Tuner
Valves / Tubes 4: DK40 DAF40 DAF41 DL41
schematic requested
Principle Super-Heterodyne (Super in general); IF-Freq. 468 kHz; 2 AF-stage(s)
Wave bands Broadcast, Long Wave and Short Wave.
Power type and voltage Line / Batteries (any type) / AC-DC 115; 130; 220 / 4,5 & 90 Volt
Loudspeaker/pwr.out Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 cm = 6.7 inch
from Radiomuseum.org Model: LS412UB
Material Leather / canvas / plastic - over other material
Shape Portable, e.g. Portable Radio (with or without mains > 8 inch).
Dimensions (WHD) 370 x 260 x 140 mm / 14.6 x 10.2 x 5.5 inch
Notes Beim Entnehmen des Netzkabels automatische Umschaltung auf Netz.

This model was suggested by Jürgen Bauch.
