For model Studio Line 967 Kombi Total 22AH967 /50 /50S, Philips - Österreich:
Aus original Dokumentation

Country:  Austria
Manufacturer / Brand:  Philips - Österreich
Year: 1976 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 87:
Main principle Super-Heterodyne (Super in general); ZF/IF 10700 kHz
Wave bands FM Broadcast Band Only
Details Other Combination - see Notes
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Studio Line 967 Kombi Total 22AH967 /50 /50S - Philips - Österreich
Material Various materials
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 720 x 150 x 400 mm / 28.3 x 5.9 x 15.7 inch
Notes

Stereo-Steuergerät. 6 ICs.
Abstimmanzeige mit Leuchtdioden. 5 Tasten für Sendervorwahl.
Phono-Chassis = Automatic Record-Player 22GC018 /00 und
Cassetten-Recorder = N2510 HiFi mit Dolby und DNL.
2 Lautsprecherboxen 22AH465 im Lieferumfang.

Source of data -- Original-techn. papers.

Model page created by Karl Günther Goldsteiner. See "Data change" for further contributors.
