CRT Analyzer / Rejuvenator RT-501B
Promax; Barcelona
- Country
- Spain
- Manufacturer / Brand
- Promax; Barcelona
- Year
- 1990 ?
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 185898
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 4
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 220; 240 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: CRT Analyzer / Rejuvenator RT-501B - Promax; Barcelona
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 165 x 103 x 260 mm / 6.5 x 4.1 x 10.2 inch
- Net weight (2.2 lb = 1 kg)
- 2 kg / 4 lb 6.5 oz (4.405 lb)
- Source of data
- - - Data from my own collection
- Literature/Schematics (1)
- -- Schematic
- Author
- Model page created by Gil Silva. See "Data change" for further contributors.
