Voltímetro Electrónico VT-150
Promax; Barcelona
- Country
- Spain
- Manufacturer / Brand
- Promax; Barcelona
- Year
- 1972
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 173041
Ebay 180472724007 chollos_informatica
Anuncio REDE 215 Octubre 1972
Catálogo posiblemente de 1980
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 5
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 125; 220 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Voltímetro Electrónico VT-150 - Promax; Barcelona
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 140 x 185 x 265 mm / 5.5 x 7.3 x 10.4 inch
- Notes
- Semiconductores listados uno por tipo.
Each semiconductors type listed once.
- Net weight (2.2 lb = 1 kg)
- 3.6 kg / 7 lb 14.9 oz (7.93 lb)
- Literature/Schematics (1)
- -- Original-techn. papers. (Revista Española De Electrónica 215 Octubre 1972)
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
