Micronta Digital Multimeter 22-195

Micronta Digital Multimeter 22-195; Radio Shack Tandy, (ID = 1010679) Equipment

Micronta Digital Multimeter 22-195; Radio Shack Tandy, (ID = 1010680) Equipment

Micronta Digital Multimeter 22-195; Radio Shack Tandy, (ID = 1010681) Equipment

Micronta Digital Multimeter 22-195; Radio Shack Tandy, (ID = 1010682) Equipment

Micronta Digital Multimeter 22-195; Radio Shack Tandy, (ID = 1010683) Equipment

Micronta Digital Multimeter 22-195; Radio Shack Tandy, (ID = 1010684) Equipment

Micronta Digital Multimeter 22-195; Radio Shack Tandy, (ID = 1010685) Equipment

Micronta Digital Multimeter 22-195; Radio Shack Tandy, (ID = 1010686) Equipment

Micronta Digital Multimeter 22-195; Radio Shack Tandy, (ID = 1010687) Equipment

Micronta Digital Multimeter 22-195; Radio Shack Tandy, (ID = 1010688) Equipment
Micronta Digital Multimeter 22-195; Radio Shack Tandy, (ID = 994154) Equipment Micronta Digital Multimeter 22-195; Radio Shack Tandy, (ID = 1448214) Equipment
Use red slider bar for more.
Micronta Digital Multimeter 22-195; Radio Shack Tandy, (ID = 994154) Equipment
Radio Shack Tandy,: Micronta Digital Multimeter 22-195 [Equipment] ID = 994154 933x667
Select picture or schematic to display from thumbnails on the right and click for download.
For model Micronta Digital Multimeter 22-195, Radio Shack (Tandy, Realistic); USA

Country:  United States of America (USA)
Manufacturer / Brand:  Radio Shack (Tandy, Realistic); USA
Year: 1986 Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) 3:
Wave bands - without
Details
Power type and voltage Dry Batteries / 4 x 1.5 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Micronta Digital Multimeter 22-195 - Radio Shack Tandy, Realistic;
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 200 x 120 x 67 mm / 7.9 x 4.7 x 2.6 inch
Notes En plus des trois transistors, il y a trois circuit-intégrés.
Affichage 3-1/2 chiffres. Sélection automatique ou manuelle des gammes de mesure.
Polarité automatique. Témoin de dépassement d'échelle.
Tension dc : 0.3, 3, 30, 300, 1 kV.
Tension ac : 3, 30, 300, 750 V rms, de 45 Hz à 10 kHz.
Intensité dc : 0.3, 10A.
Intensité ac : 0.3, 10A.
Résistance : 0.3 kΩ, 3 kΩ, 30 kΩ, 300 kΩ, 3 MΩ, 30 MΩ. Fonction continuité et contrôle des diodes.
hFE des transistors @ iB= 10µA & Vce= 2V.
Fonction mémoire.
Impédance d'entrée: 10 MΩ en Vdc & Vac (>300 MΩ sur la gamme 300 mV dc).
Net weight (2.2 lb = 1 kg) 0.660 kg / 1 lb 7.3 oz (1.454 lb)
Price in first year of sale 690.00 FF
Source of data - - Manufacturers Literature
Literature/Schematics (1) - - Manufacturers Literature

Model page created by Jean Marchal. See "Data change" for further contributors.
