Megohmmeter IM6

Megohmmeter IM6; Radiometer; (ID = 433780) Equipment Megohmmeter IM6; Radiometer; (ID = 433786) Equipment
Megohmmeter IM6; Radiometer; (ID = 433782) Equipment Megohmmeter IM6; Radiometer; (ID = 433781) Equipment
Megohmmeter IM6; Radiometer; (ID = 433783) Equipment Megohmmeter IM6; Radiometer; (ID = 433784) Equipment
Megohmmeter IM6; Radiometer; (ID = 433785) Equipment
Use red slider bar for more.
Megohmmeter IM6; Radiometer; (ID = 433780) Equipment
Radiometer;: Megohmmeter IM6 [Equipment] ID = 433780 850x583
Select picture or schematic to display from thumbnails on the right and click for download.
For model Megohmmeter IM6, Radiometer; Copenhagen

Country:  Denmark
Manufacturer / Brand:  Radiometer; Copenhagen
Year: 1972 ?? Type: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
schematic requested
Details
Power type and voltage Alternating Current supply (AC) / 115; 220 Volt
Loudspeaker
Power out
from Radiomuseum.org Model: Megohmmeter IM6 - Radiometer; Copenhagen
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 300 x 140 x 305 mm / 11.8 x 5.5 x 12 inch
Notes Obere Logarithmische Skala erfasst 2 Dekaden 0,1 - 1 - 10.
Messbereiche in 8 Stufen dekadisch einstellbar. Faktoren:
10 Megohm;
100 Megohm;
1 Gigaohm;
10 Gigaohm;
100 Gigaohm;
1 Teraohm;
10 Teraohm;
100 Teraohm.
Somit Gesamtmessbereich von 1 Megohm bis 1000 Teraohm. Untere logarithmische Skala erfasst alle 9 Dekaden von 1 Megohm bis 1000 Teraohm.
Messgenauigkeit: 5%
Strommessbereich: 1 pA bis 1 mA.
Prüfspannung: 0 bis 999 Volt in 1 Volt-Schritten einstellbar.
Net weight (2.2 lb = 1 kg) 5.7 kg / 12 lb 8.9 oz (12.555 lb)
Source of data - - Data from my own collection

Model page created by Rudolf Osterkamp. See "Data change" for further contributors.
