M-1101 Ch= 12AX22

M-1101 Ch= 12AX22; Raytheon Mfg. Co.; (ID = 1666452) Television

M-1101 Ch= 12AX22; Raytheon Mfg. Co.; (ID = 1666453) Television

M-1101 Ch= 12AX22; Raytheon Mfg. Co.; (ID = 1666454) Television

M-1101 Ch= 12AX22; Raytheon Mfg. Co.; (ID = 1666455) Television

M-1101 Ch= 12AX22; Raytheon Mfg. Co.; (ID = 1666456) Television

M-1101 Ch= 12AX22; Raytheon Mfg. Co.; (ID = 1666457) Television

M-1101 Ch= 12AX22; Raytheon Mfg. Co.; (ID = 1666459) Television

M-1101 Ch= 12AX22; Raytheon Mfg. Co.; (ID = 1666460) Television

M-1101 Ch= 12AX22; Raytheon Mfg. Co.; (ID = 1666461) Television

M-1101 Ch= 12AX22; Raytheon Mfg. Co.; (ID = 1666462) Television
M-1101 Ch= 12AX22; Raytheon Mfg. Co.; (ID = 1666445) Television
Use red slider bar for more.
M-1101 Ch= 12AX22; Raytheon Mfg. Co.; (ID = 1666445) Television
Raytheon Mfg. Co.;: M-1101 Ch= 12AX22 [Television] ID = 1666445 933x777
Select picture or schematic to display from thumbnails on the right and click for download.
For model M-1101 Ch= 12AX22, Raytheon Mfg. Co.; Cambridge, USA (also tubes):
Sams Photofact Vol.10/50 Date 5-50 Set 94 Folder 8

Country:  United States of America (USA)
Manufacturer / Brand:  Raytheon Mfg. Co.; Cambridge, USA (also tubes)
Year: 1949 ? Type: Television Receiver (TV) or Monitor
Valves / Tubes 20: 6AG5 6J6 6AU6 6AU6 6AU6 6AU6 6AL5 12AU7 6SL7GT 6AU6 6T8 6K6GT 6SN7GT 6AL5 6SN7GT 6BQ6 6W4GT 1X2 5U4G 12LP4
Principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 110-120 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet. / Ø 6 inch = 15.2 cm
Power out
from Radiomuseum.org Model: M-1101 Ch= 12AX22 - Raytheon Mfg. Co.; Cambridge,
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 19 x 19 x 19 inch / 483 x 483 x 483 mm
Notes Raytheon M-1101;
12" round CRT porthole style b/w TV with US standard VHF tuner. RCA jack for phono-in, mahogany cabinet.
Source of data -- Collector info (Sammler)
Mentioned in Photofact Folder, Howard W. SAMS (Vol.10/50 Date 5-50 94-8 Set 94 Folder 8)

Model page created by a member from A. See "Data change" for further contributors.

All listed radios etc. from Raytheon Mfg. Co.; Cambridge, USA (also tubes)
Here you find 140 models, 122 with images and 58 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
