• Year
  • 1979 ??
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 89320

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 1
  • Number of Transistors
  • 22
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Line / Storage batteries (perhaps also batteries) / 220 / 12 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Power out
  • 1 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Combi Vision RF3301 - Robotron-Elektronik Radeberg,
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 430 x 300 x 270 mm / 16.9 x 11.8 x 10.6 inch
  • Notes
  • Kofferfernseher schwarz-weiß; CCIR VHF-Band I und III, UHF-Kanal 21-60; 8 Speicherplätze, Teleskopantenne.
    Anschlüsse: TB, Außenantenne, 12 V. Modular aufgebaut, ICs: A240, A223, A210D.
    Vorgestellt auf der Leipziger Frühjahrsmesse 1979.
  • Net weight (2.2 lb = 1 kg)
  • 8.7 kg / 19 lb 2.6 oz (19.163 lb)
  • Price in first year of sale
  • 1,730.00 Mark
  • Source of data
  • - - Data from my own collection
  • Mentioned in
  • Sortimentskatalog Elektroakustik (DDR, 1987)
  • Literature/Schematics (1)
  • Radio Fernsehen Elektronik Jahrgang 1980 Heft 9 Seite575 ff.
  • Author
  • Model page created by Wolfgang Lill. See "Data change" for further contributors.
