FM/AM Radio Cassette RD-438X
Sharp; Osaka
- Country
- Japan
- Manufacturer / Brand
- Sharp; Osaka
- Year
- 1973–1976
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 220266
-
- alternative name: Hayakawa Electric Co.Ltd.
Bild aus Sharp Service Unterlagen
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 455/10700 kHz
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Line / Batteries (any type) / 10; 220; 240/C: 4 x 1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
- Power out
- 1.8 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: FM/AM Radio Cassette RD-438X - Sharp; Osaka
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 297 x 188 x 84 mm / 11.7 x 7.4 x 3.3 inch
- Notes
-
Radio Recorder; Frequency, AM 530 to 1605 kHz and FM 88 to 108 MHz, AC 50/60 Hz.
This model sold in Australia between 1973 and 1976 for $135.00
- Net weight (2.2 lb = 1 kg)
- 3 kg / 6 lb 9.7 oz (6.608 lb)
- Mentioned in
- Sharp Service Unterlagen
- Literature/Schematics (1)
- Mingay's Price Service (Feb 1974 to Feb 1976.)
- Author
- Model page created by Josef Pilz. See "Data change" for further contributors.
