FY-26

FY-26; Sharp; Osaka (ID = 406322) Radio

FY-26; Sharp; Osaka (ID = 406323) Radio

FY-26; Sharp; Osaka (ID = 406324) Radio

FY-26; Sharp; Osaka (ID = 406325) Radio

FY-26; Sharp; Osaka (ID = 406326) Radio
FY-26; Sharp; Osaka (ID = 1699102) Radio FY-26; Sharp; Osaka (ID = 406327) Radio
FY-26; Sharp; Osaka (ID = 1704419) Radio
Use red slider bar for more.
FY-26; Sharp; Osaka (ID = 1699102) Radio
Sharp; Osaka: FY-26 [Radio] ID = 1699102 933x1059
Select picture or schematic to display from thumbnails on the right and click for download.
For model FY-26, Sharp; Osaka

Country:  Japan
Manufacturer / Brand:  Sharp; Osaka
alternative name

Hayakawa Electric Co.Ltd.
Year: 1975 ?? Type: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10:
Principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Tuned circuits 8 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, Long Wave and FM.
Details
Power type and voltage Dry Batteries / 4×1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch
Power out 1.5 W (unknown quality)
from Radiomuseum.org Model: FY-26 - Sharp; Osaka
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (usable without mains)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Josef Pilz. See "Data change" for further contributors.
