SB-EX3; Technics brand (ID = 1291135) Speaker-P

SB-EX3; Technics brand (ID = 1291138) Speaker-P

SB-EX3; Technics brand (ID = 1291139) Speaker-P
SB-EX3; Technics brand (ID = 872119) Speaker-P SB-EX3; Technics brand (ID = 872120) Speaker-P
SB-EX3; Technics brand (ID = 1291096) Speaker-P
Use red slider bar for more.
SB-EX3; Technics brand (ID = 872119) Speaker-P
Technics brand: SB-EX3 [Speaker-P] ID = 872119 741x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model SB-EX3, Technics (brand)

Country:  Japan
Manufacturer / Brand:  Technics (brand)
Year: 1992 ?? Type: Loudspeaker (speaker or headphone)
Details
Power type and voltage No Power needed
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: SB-EX3 - Technics brand
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Dimensions (WHD) 235 x 880 x 270 mm / 9.3 x 34.6 x 10.6 inch
Notes Dreiwege Box 125 Watt nach DIN.
Source of data - - Data from my own collection

Model page created by Claus Marker. See "Data change" for further contributors.
