R4400-111 (R 4400-111)

ID = 134928

Videoton; : R4400-111 [Radio] ID = 483857 933x392

H-Videoton-R4400-111

Country: Hungary	Manufacturer/Brand: Videoton; Székesfehérvár
Year: 1965 ??	Type: Radio or Tuner
Valves / Tubes	5: ECC85 ECH81 EBF89 ECL86 EM84

Principle	Super-Heterodyne (Super in general)
Tuned circuits	6 AM circuit(s); 8 FM-circuit(s)
Wave bands	Broadcast, Long Wave, Short Wave plus FM.
Power type and voltage	Alternating Current supply (AC) / 110; 127; 150; 220; 240 Volt
Loudspeaker/pwr.out	Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / 1.5 W
from Radiomuseum.org	Model: R4400-111
Material	Wooden case
Shape	Tablemodel with Push Buttons.
Dimensions (WHD)	505 x 210 x 170 mm / 19.9 x 8.3 x 6.7 inch

This model was suggested by Klemens Rhode.
