• Country
• United States of America (USA)

• Manufacturer / Brand
• Webster Electric (Electrical) Co. (Teletalk); Racine (WI)

• Year
• 1954

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 147930

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• 12BA6 50C5 35W4

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• AC/DC-set / 110 - 125 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm

• from Radiomuseum.org
• Model: 606S - Webster Electric Electrical Co

• Shape
• Tablemodel, with any shape - general.

• Notes
• The Webster Model 606S is an AC/DC operated Intercommunication System Master Unit.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Date 12-54, Set 260, Folder 17)

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
