Royal 1000 RG1000Y

Royal 1000 RG1000Y; Zenith Radio Corp.; (ID = 504423) Radio Royal 1000 RG1000Y; Zenith Radio Corp.; (ID = 504424) Radio
Royal 1000 RG1000Y; Zenith Radio Corp.; (ID = 504425) Radio Royal 1000 RG1000Y; Zenith Radio Corp.; (ID = 504426) Radio
Royal 1000 RG1000Y; Zenith Radio Corp.; (ID = 504427) Radio
Royal 1000 RG1000Y; Zenith Radio Corp.; (ID = 504423) Radio
Zenith Radio Corp.;: Royal 1000 RG1000Y [Radio] ID = 504423 639x484
With courtesy from Ebayseller music-galore.

Country:  United States of America (USA)
Manufacturer/Brand:  Zenith Radio Corp.; Chicago, Illinois
Year: 1980 ?? Type: Radio or Tuner
Semiconductors (the count is only for transistors) Semiconductors present.:
Principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Power type and voltage Line / Batteries (any type) / 120; 4 x 1,5 Volt
Loudspeaker/pwr.out Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
from Radiomuseum.org Model: Royal 1000 RG1000Y
Material Modern plastics (no Bakelite or Catalin)
Shape Portable, e.g. Portable Radio (with or without mains > 8 inch).
Dimensions (WHD) 12 x 9 x 4 inch / 305 x 229 x 102 mm
Notes Zenith Royal 1000, RG1000Y;
AM-MW, FM,
VHF-Hi: 144 - 174 MHz,
VHF-Lo 30 - 50 MHz & UHF: 450 - 470 MHz,
tone and squelch control, two telescopic antennas, dial light, AFC,
made in Hong-Kong, not to be confused with the Transoceanic 1000!

This model was suggested by Anonymous 38 Collector.
