5T34 Ch= 5T3

5T34 Ch= 5T3; Admiral brand (ID = 1119685) Radio

5T34 Ch= 5T3; Admiral brand (ID = 1119686) Radio

5T34 Ch= 5T3; Admiral brand (ID = 1119687) Radio

5T34 Ch= 5T3; Admiral brand (ID = 1119688) Radio

5T34 Ch= 5T3; Admiral brand (ID = 1119689) Radio

5T34 Ch= 5T3; Admiral brand (ID = 118184) Radio

5T34 Ch= 5T3; Admiral brand (ID = 118185) Radio

5T34 Ch= 5T3; Admiral brand (ID = 118186) Radio
5T34 Ch= 5T3; Admiral brand (ID = 482965) Radio
Use red slider bar for more.
5T34 Ch= 5T3; Admiral brand (ID = 482965) Radio
Admiral brand: 5T34 Ch= 5T3 [Radio] ID = 482965 578x417
Select picture or schematic to display from thumbnails on the right and click for download.
For model 5T34 Ch= 5T3, Admiral (brand) Continental Radio & Television Co.:
SAMS Photofact reference picture for models Admiral 5T31, 5T32, 5T33, 5T34 and 5T38 with chassis 5T3. The cases differ only in color.

Country:  United States of America (USA)
Manufacturer / Brand:  Admiral (brand) Continental Radio & Television Co.
alternative name

Continental Radio & TV
Year: 1954/1955 Type: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12BE6 12BA6 12AV6 50C5 35W4
Principle Super-Heterodyne (Super in general); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 117 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
Power out
from Radiomuseum.org Model: 5T34 Ch= 5T3 - Admiral brand Continental
Material Moulded (Bakelite or Plastics)
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Notes Beitman 155 shows Admiral models 5T31, 5T32, 5T33, 5T34 and 5T38 for chassis 5T3. It is the same circuit as chassis 5R3 and 5S3 on the same sheet, where only chassis 5S3 with electric clock radios differs with the colock associated switch. SAMS Potofact date 4-55, set 272, folder 1 show the Admiral models 5R32, 5R33, 5R35, 5R36, 5R37 and 5R38 with chassis 5R3 and the models 5S32, 5S33, 5S34, 5S35 and 5S38 with chassis 5S3 but without chassis 5T3. The color is given by the last digit, 1 = color black, 2 = brown, 3 = ivory, 4 = beige, 5 = red/white, 6 = turquoise/white, 7 = eony/white and 8 = green. The models have a loop antenna.
Source of data Beitman Radio Diagrams, Vol. 15, 1955

Model page created by Egon Penker. See "Data change" for further contributors.
