Stereo Tape Deck GX-635DB

ID = 120472

Akai, Tokyo: Stereo Tape Deck GX-635DB [R-Player] ID = 379011 711x700

Country: Japan	Manufacturer/Brand: Akai, Tokyo
Year: 1976	Type: Recorder and/or Player
Transistors	64:
schematic requested

Principle	Audio-Amplification
Wave bands	- without
Details	Cassette-Recorder or -Player
Power type and voltage	Alternating Current supply (AC) / 220 Volt
Loudspeaker/pwr.out	- For headphones or amp.
from Radiomuseum.org	Model: Stereo Tape Deck GX-635DB
Material	Metal case
Shape	Tablemodel, high profile (upright - NOT Cathedral nor Tombstone).
Dimensions (WHD)	440 x 485 x 240 mm / 17.3 x 19.1 x 9.4 inch

This model was suggested by Wilfried Winter.
