Auto-Tourist 725/6000; Akkord-Radio + (ID = 16104) Radio
Akkord-Radio +: Auto-Tourist 725/6000 [Radio] ID = 16104 702x479
Select picture or schematic to display from thumbnails on the right and click for download.
For model Auto-Tourist 725/6000, Akkord-Radio + Akkord Elektronik (Radios)

Country:  Germany
Manufacturer / Brand:  Akkord-Radio + Akkord Elektronik (Radios)
Year: 1964/1965 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9:
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 5 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / 6 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 18 cm = 7.1 inch
Power out 1.2 W (unknown quality)
from Radiomuseum.org Model: Auto-Tourist 725/6000 - Akkord-Radio + Akkord
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (usable also without mains)
Dimensions (WHD) 315 x 195 x 92 mm / 12.4 x 7.7 x 3.6 inch
Notes Transistoren: AF106, AF115, 3× AF116, 2× AC122, 2× AC117.
Betrieb im Auto über Autohalterung (28,- DM) aus 6-V- oder 12-V-Autobatterie. Netzbetrieb mit Netzteil (220 V) NT680B (50,- DM) möglich.
Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)
Price in first year of sale 378.00 DM
Collectors' prices
Source of data Handbuch VDRG 1964/1965 / Radiokatalog Band 1, Ernst Erb
Mentioned in Funkschau
