Minden 7.630.070 ab 300001

Minden 7.630.070 ab 300001; Blaupunkt Ideal, (ID = 282846) Car Radio

Minden 7.630.070 ab 300001; Blaupunkt Ideal, (ID = 282847) Car Radio

Minden 7.630.070 ab 300001; Blaupunkt Ideal, (ID = 282849) Car Radio

Minden 7.630.070 ab 300001; Blaupunkt Ideal, (ID = 282850) Car Radio

Minden 7.630.070 ab 300001; Blaupunkt Ideal, (ID = 282848) Car Radio
Minden 7.630.070 ab 300001; Blaupunkt Ideal, (ID = 318772) Car Radio Minden 7.630.070 ab 300001; Blaupunkt Ideal, (ID = 318773) Car Radio
Minden 7.630.070 ab 300001; Blaupunkt Ideal, (ID = 1035677) Car Radio Minden 7.630.070 ab 300001; Blaupunkt Ideal, (ID = 1297241) Car Radio
Use red slider bar for more.
Minden 7.630.070 ab 300001; Blaupunkt Ideal, (ID = 318772) Car Radio
Blaupunkt Ideal,: Minden 7.630.070 ab 300001 [Car Radio] ID = 318772 933x495
Select picture or schematic to display from thumbnails on the right and click for download.
For model Minden 7.630.070 ab 300001, Blaupunkt (Ideal), Berlin, später Hildesheim:
Q: Blaupunkt Service

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1970/1971 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 9: BF255 BF255 BF255 BF254 BF254 BC148 BSW73 AD161 AD162
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Minden 7.630.070 ab 300001 - Blaupunkt Ideal, Berlin,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 153 x 35 x 90 mm / 6 x 1.4 x 3.5 inch
Notes Hobby-Autoradio, speziell für den Selbsteinbau; für Einbau oder Aufbau, Hobby-Einbausatz. Skalenmarkierungen für Deutschlandfunk und Radio Luxemburg.
Collectors' prices
External source of data Erb
Source of data Handbuch VDRG 1970/1971
Literature/Schematics (1) -- Original-techn. papers.
