400N DeLuxe series (De Luxe) general, samples & unknown

Capehart Corp.; Fort Wayne, IN - see also Farnsworth

  • Year
  • 1946–1948
perfect model
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 224790

 Technical Specifications

  • Number of Tubes
  • 28
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • Broadcast, Short Wave plus FM or UHF.
  • Details
  • Record-Changer, both sides!
  • Power type and voltage
  • Alternating Current supply (AC) / 245 Watts, 60 cycles, 117 = 105 - 125 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 15 inch = 38.1 cm
  • Power out
  • 30 W (undistorted)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 400N DeLuxe series general, samples & unknown - Capehart Corp.; Fort Wayne, IN
  • Shape
  • Console with any shape - in general
  • Notes
  • 400N DeLuxe series (De Luxe)
    general, samples & unknown
    This model page is for collecting uncertain or unknown pictures or facts for a given season. Can also contain the different pictures for the different models from sets of this season.
    For season N, 1946/48 there were at least the following general models offered:
    406N, 413N, 414N, 112N2, 114N2, 114N3, 115N and 116N4.
    See the other model pages under their model type name.
    For an overview about the cabinets during the different seasons see this article.

    The Capehart 400 series were introduced for season 1931/32 without suffix, followed by A 1932/33, B 1933/34 etc. through to season 1948-50. See here the "Common information for the Capehart model pages for the 1930s and 1940s".

  • Author
  • Model page created by Ernst Erb. See "Data change" for further contributors.
