Dual-Beam Oscilloscope 279

Dual-Beam Oscilloscope 279; DuMont Labs, Allen B (ID = 475262) Equipment Dual-Beam Oscilloscope 279; DuMont Labs, Allen B (ID = 475261) Equipment
Dual-Beam Oscilloscope 279; DuMont Labs, Allen B (ID = 475263) Equipment Dual-Beam Oscilloscope 279; DuMont Labs, Allen B (ID = 475265) Equipment
Dual-Beam Oscilloscope 279; DuMont Labs, Allen B (ID = 475266) Equipment Dual-Beam Oscilloscope 279; DuMont Labs, Allen B (ID = 475267) Equipment
Use red slider bar for more.
Dual-Beam Oscilloscope 279; DuMont Labs, Allen B (ID = 475262) Equipment
DuMont Labs, Allen B: Dual-Beam Oscilloscope 279 [Equipment] ID = 475262 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Dual-Beam Oscilloscope 279, DuMont Labs, Allen B., Inc.

Country:  United States of America (USA)
Manufacturer / Brand:  DuMont Labs, Allen B., Inc.
alternative name

Dumont Television & Radio
Year: 1946 ?? Category: Service- or Lab Equipment
Valves / Tubes 25: 6AG7 6J5 6SN7 6Q5 6SL7GT 0D3 6H6 5U4 6B4 6SJ7 6X5 3B24 2X2A unknown_Tube
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 115; 230 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Dual-Beam Oscilloscope 279 - DuMont Labs, Allen B., Inc.
Material Metal case
Shape Rack
Dimensions (WHD) 19 x 16 x 22 inch / 483 x 406 x 559 mm
Notes True Dual-beam Oscilloscope with seperate sweeps and amps.
Picture tube 5".
Max. vertical frequency (measured) 200 kHz at -3 dB.
Max. vertical sensitivity (measured) 200 mV/cm.
Some tube types are built in several times.
Net weight (2.2 lb = 1 kg) 40.6 kg / 89 lb 6.8 oz (89.427 lb)
Source of data - - Data from my own collection

Model page created by Basil Burkhardt. See "Data change" for further contributors.
