• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke)

• Year
• 1965

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 210975

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Stereo-Plattenwechsler Automatic 36 - Grundig Radio-Vertrieb, RVF,

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 13.75 x 11.625 x 5 inch / 349 x 295 x 127 mm

• Notes

• Als Grundig Automatic 36 vertriebener Philips-Plattenwechsler 22GC036 /55 mit Stereo-Tonkopf 22GP200, Nadel umschaltbar für Micro - und Normalrille.

  Fest verdrahtet für 110 V, Umschaltung auf 220 V durch Umlöten der Motoranschlüsse.

• Source of data
• - - Manufacturers Literature

• Author
• Model page created by Oscar Herrera. See "Data change" for further contributors.
