• Year
  • 1963
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 83871
    • Brand: Elektrot.Fabrik Ludwig Neumann

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 17
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Weltblick 611TR [Nr. < 306000] - Ingelen, Elektrotechnische
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 700 x 510 x 370 mm / 27.6 x 20.1 x 14.6 inch
  • Notes
  • Empfangsbereich VHF + UHF . Ausführung als nur UHF-vorbereitet 7540.- öS.
  • Net weight (2.2 lb = 1 kg)
  • 35 kg / 77 lb 1.5 oz (77.093 lb)
  • Price in first year of sale
  • 7,840.00 öS
  • Source of data
  • -- Original prospect or advert / Radiokatalog Band 2, Ernst Erb
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
