• Country
• Germany

• Manufacturer / Brand
• Lumophon, Bruckner & Stark, BSN; Nürnberg

• Year
• 1968–1972

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 27325

• • Brand: Lumeta

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 11

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Tuned circuits
• 7 AM circuit(s)     11 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 4 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Violetta 400 - Lumophon, Bruckner & Stark,

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 650 x 170 x 180 mm / 25.6 x 6.7 x 7.1 inch

• Notes
• Gehäuse: Edelholz, hell mattiert oder Schleiflack, weiss. 2 Skalenbirnchen à 7V,0,1 A.

• Net weight (2.2 lb = 1 kg)
• 5 kg / 11 lb 0.2 oz (11.013 lb)

• External source of data
• erb

• Source of data
• Handbuch VDRG 1968/1969

• Mentioned in
• Handbuch VDRG 1970/1971
