• Country
• United States of America (USA)

• Manufacturer / Brand
• Merrell Electronics Inc.; New York

• Year
• 1960 ??

• Category
• Kit (Parts plus instruction) or building instructions only

• Radiomuseum.org ID
• 208846

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 9

• Valves / Tubes
• ECC83 ECC83 ECC81 ECC81 7408 7408 7408 7408 5U4

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 30 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Stereo Amplifier Kit SA 30 - Merrell Electronics Inc.; New

• Shape
• Chassis only or for «building in»

• Notes

• Integrated amplifier.

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by Yukihiro Shiotsubo. See "Data change" for further contributors.
