ECC83

Information - Help
ID = 411

Country:
Europe
Brand:
Tube type:  Double Triode   Audio Frequency
Identical to ECC83 = 12AX7 = B339 = 95-127-01 = ECC83S = 6L13 = CM1
Similar Tubes
Normally replaceable-slightly different:
  0AX7 ; 12AX7A ; CV492 ; E2164
Other class quality (otherwise equal):
  7025 ; CV4004 ; E83CC ; M8137
Other characteristic (electr. data):
  12AY7 ; 6N4_China
Other base and data slightly different:
  2C52
Other base and other heater:
  6EU7 ; ECC808
Multiple differences or of other kind:
  5751 ; 6DR4 ; 7729
First year 1954 Tube leaflet collection E.Erb Analysis by original leaflets
First Source (s)
Feb.1954 : Funkschau # 3
Predecessor Tubes 12AX7
Successor Tubes 1963   ECC808   5751WA

Base Noval, 9 pin miniature (USA pico-9) B9A
Was used by Radio/TV-reception etc.
Filament Vf 12.6 Volts / If 0.15 Ampere / Indirect / Specified voltage AND current AC/DC
Description

European code for 12AX7 high-gain twin-triode.


Tube prices 252 Tube prices (visible for members only)

ECC83: Courtesy Bureau Belper (De Muiderkring, Bussum), Scan Frank Philipse
Karel De Reus †

no15_2.png ECC83: RTT 1974 (Franzis) 13. Auflage
Martin Renz

More ...

Just Qvigstad
ECC83: Valvo
Dietrich Grötzer

More ...
Usage in Models 15= 1954?? ; 8= 1954? ; 78= 1954 ; 40= 1955?? ; 30= 1955? ; 110= 1955 ; 35= 1956?? ; 33= 1956? ; 153= 1956 ; 18= 1957?? ; 66= 1957? ; 194= 1957 ; 27= 1958?? ; 104= 1958? ; 268= 1958 ; 27= 1959?? ; 257= 1959? ; 460= 1959 ; 156= 1960?? ; 114= 1960? ; 346= 1960 ; 37= 1961?? ; 103= 1961? ; 316= 1961 ; 51= 1962?? ; 103= 1962? ; 292= 1962 ; 41= 1963?? ; 86= 1963? ; 303= 1963 ; 39= 1964?? ; 95= 1964? ; 262= 1964 ; 104= 1965?? ; 80= 1965? ; 206= 1965 ; 30= 1966?? ; 62= 1966? ; 127= 1966 ; 15= 1967?? ; 35= 1967? ; 77= 1967 ; 24= 1968?? ; 22= 1968? ; 37= 1968 ; 19= 1969?? ; 9= 1969? ; 21= 1969 ; 30= 1970?? ; 11= 1970? ; 6= 1970 ; 3= 1971?? ; 4= 1971? ; 3= 1971 ; 1= 1972?? ; 5= 1972 ; 4= 1973? ; 6= 1973 ; 1= 1974?? ; 3= 1974? ; 2= 1974 ; 5= 1975?? ; 1= 1975? ; 2= 1976 ; 1= 1978?? ; 2= 1978? ; 1= 1980?? ; 1= 1981?? ; 1= 1982? ; 1= 1984?? ; 1= 1984 ; 1= 1986?? ; 1= 1986 ; 1= 1987 ; 1= 1991 ; 1= 1992? ; 2= 1993 ; 1= 1995?? ; 1= 1995 ; 2= 1996 ; 2= 1997? ; 1= 1999 ; 2= 2000 ; 1= 2002 ; 1= 2003?? ; 1= 2003 ; 2= 2005?? ; 1= 2005? ; 2= 2006? ; 1= 2006 ; 1= 2007 ; 1= 2008 ; 1= 2011 ; 1= 2013 ; 1= 2015 ; 1= 2018 ; 1= 2019 ; 2= 9999? ; 21= 9999

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):5285


Collection of



ECC83


Forum contributions about this tube
ECC83
Threads: 1 | Posts: 3
Hits: 1146     Replies: 2
Valvo ECC83 - Unbekanntes Emblem
Heinz LUCAS
04.Oct.21
  1

Aus einem alten Bestand bekam ich eine ECC83 von Valvo. Wer kann mir etwas über das Emblem auf der Rückseite sagen?

Dietmar Rudolph † 6.1.22
04.Oct.21
  2

Das Symbol könnte das "geflügelte" Rad der Eisenbahn sein. Auch spricht "DB" (?) oder "DR" (?) dafür.

Hier noch ein zeitgenössisches Bild dazu.

MfG DR

Heinz LUCAS
04.Oct.21
  3

Danke Dr. Rudolph,

Ihr Hinweis hat mich weiter gebracht.

Mit einem Vergrößerungsglas konnte ich unter dem geflügelten Logo eindeutig DR erkennen. Nach Eingabe von "Embleme der Deutschen Reichsbahn der DDR" in Google wird ein Flügelrad in ähnlicher Darstellung  gezeigt. Das könnte bedeuten, Valvo hat diese Röhren für das Staatsunternehmen gefertigt.

Es grüßt

Heinz Lucas


ECC83
End of forum contributions about this tube
