• Country
• Germany

• Manufacturer / Brand
• Neckermann-Versand KG; Frankfurt a.M.

• Year
• 1954/1954

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 76485

• • Brand: Twen Tone

• Number of Tubes
• 6

• Valves / Tubes
• ECC85 ECH81 EF41 EABC80 EM34 EL41

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110, 125, 220, 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: WR 9665 W - Neckermann-Versand KG;

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 495 x 300 x 225 mm / 19.5 x 11.8 x 8.9 inch

• Notes
• Hersteller AWB = Apparate-Werk Bayern, Dachau. Leistungsaufnahme 40 Watt.

• Net weight (2.2 lb = 1 kg)
• 7.4 kg / 16 lb 4.8 oz (16.3 lb)

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Author
• Model page created by Lutwin Berndt † 5.10.14. See "Data change" for further contributors.
