Electronic Engineer / Elektronik Experimente EE-20; Philips; Eindhoven (ID = 121606) Kit
Philips; Eindhoven: Electronic Engineer / Elektronik Experimente EE-20 [Kit] ID = 121606 900x617
Select picture or schematic to display from thumbnails on the right and click for download.
For model Electronic Engineer / Elektronik Experimente EE-20, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1963–1965 ? Type: Kit (Parts plus Instruction) or Blueprint only
Semiconductors (the count is only for transistors) 3: AF116 AC126 AC126
Tuned circuits 1 AM circuit(s)
Details
Power type and voltage Dry Batteries / 2 x 4,5 Volt
Loudspeaker 2 Loudspeakers / Ø 7.5 cm = 3 inch
Power out
from Radiomuseum.org Model: Electronic Engineer / Elektronik Experimente EE-20 - Philips; Eindhoven tubes
Material Various materials
Dimensions (WHD) 360 x 60 x 260 mm / 14.2 x 2.4 x 10.2 inch
Notes

"All Transistor"-Baukasten fur 8 plus 22 Experimente.

Diese werden genau wie die Bedienelemente auf einer Grundplatte aus Presspappe aufgebaut, wobei die Verbindung durch eine Federkonstruktion hergestellt werden. Auch die - langbeinigen - Transistoren werden so verschaltet. (erst später wurden die empfindlicheren Bauteile auf kleine Platinen montiert)



Source of data -- Collector info (Sammler)

Model page created by Hugo Sneyers. See "Data change" for further contributors.
