Electronic VAΩ Meter PM2505 /04

• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1985 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 173037

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Dry Batteries / 2 x 9 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Bakelite or Plastics (type unknown)

• from Radiomuseum.org
• Model: Electronic VAΩ Meter PM2505 /04 - Philips; Eindhoven tubes

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 116 x 172 x 66 mm / 4.6 x 6.8 x 2.6 inch

• Notes
• Messbereich Volt AC/DC: 0,1 V bis 1000 V in 9 Teilbereichen.
  Strommessbereich AC/DC: 1 µA bis 10 A in 12 Teilbereichen.
  Widerstandsmessung: 100 Ohm bis 30 MOhm.
  dB-Anzeige: -20dB bis 2 dB
  Polaritäts- bzw. AC-Anzeige mit separatem Anzeigeinstrument.

• Net weight (2.2 lb = 1 kg)
• 0.730 kg / 1 lb 9.7 oz (1.608 lb)

• Source of data
• -- Original prospect or advert

• Mentioned in
• -- Original prospect or advert (Philips Katalog Test & Messtechnik 85 / 86)

• Author
• Model page created by Horst Schneider. See "Data change" for further contributors.
