For model 9T246 KCS38, RCA (RCA Victor Co. Inc.); New York (NY):
Scan einer Werbung zum Modell

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1950 ? Type: Television Receiver (TV) or Monitor
Valves / Tubes 24: 6AG5 6AG5 6J6 6BA6 6AG5 6BA6 6AG5 6AL5 12AU7 6AU6 6AU6 6AL5 6AV6 6K6GT 6SN7GT 6SN7GT 6SN7GT 6K6GT 6SN7GT 6BG6G 6W4GT 1B3GT 5U4G 12LP4
Principle Superhet with RF-stage; 2 AF stage(s)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 60 cycles, 110-120 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet.
Power out
from Radiomuseum.org Model: 9T246 KCS38 - RCA RCA Victor Co. Inc.; New
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 21 x 14 x 19 inch / 533 x 356 x 483 mm
Notes

The RCA 9T246 is a 12" b/w TV with US standard VHF Tuner channels 2 thru 13. Equipped with chassis KCS38 and picture tube 12LP4.

Price in first year of sale 199.00 $
Collectors' prices
Source of data -- Collector info (Sammler)
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 93 Folder 9 Date 5-50)
