Superette (Radiolette) R7-AC

Superette R7-AC; RCA RCA Victor Co. (ID = 972163) Radio

Superette R7-AC; RCA RCA Victor Co. (ID = 972164) Radio

Superette R7-AC; RCA RCA Victor Co. (ID = 972165) Radio

Superette R7-AC; RCA RCA Victor Co. (ID = 972166) Radio

Superette R7-AC; RCA RCA Victor Co. (ID = 972167) Radio

Superette R7-AC; RCA RCA Victor Co. (ID = 972168) Radio

Superette R7-AC; RCA RCA Victor Co. (ID = 972169) Radio

Superette R7-AC; RCA RCA Victor Co. (ID = 972170) Radio

Superette R7-AC; RCA RCA Victor Co. (ID = 972171) Radio

Superette R7-AC; RCA RCA Victor Co. (ID = 972172) Radio
Superette R7-AC; RCA RCA Victor Co. (ID = 1080248) Radio Superette R7-AC; RCA RCA Victor Co. (ID = 1080120) Radio
Superette R7-AC; RCA RCA Victor Co. (ID = 1080123) Radio Superette R7-AC; RCA RCA Victor Co. (ID = 1080121) Radio
Superette R7-AC; RCA RCA Victor Co. (ID = 1521549) Radio
Use red slider bar for more.
Superette R7-AC; RCA RCA Victor Co. (ID = 1080248) Radio
RCA RCA Victor Co.: Superette R7-AC [Radio] ID = 1080248 681x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model Superette (Radiolette) R7-AC, RCA (RCA Victor Co. Inc.); New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1932 Type: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: 35 24 27 35 27 45 45 80
Principle Superhet with RF-stage; ZF/IF 175 kHz; 1 AF stage(s); Anode bend detection
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Superette R7-AC - RCA RCA Victor Co. Inc.; New
Material Wooden case
Shape Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
Dimensions (WHD) 14 x 19 x 10 inch / 356 x 483 x 254 mm
Notes

Push-pull af output.

Stein calls this radio Radiolette.

Net weight (2.2 lb = 1 kg) 37 lb (37 lb 0 oz) / 16.798 kg
Price in first year of sale 69.00 $
Collectors' prices
External source of data Ernst Erb
Source of data Radio Collector`sGuide 1921-
Circuit diagram reference Rider's Perpetual, Volume 1 = 1931/1934 (for 1919-1931)
Mentioned in The Radio CollectorGrinder, 1995
Literature/Schematics (1) Rider's Perpetual, Volume 2 = 1932 and before
Literature/Schematics (2) RCA Victor Service Notes "Red Book" Series
Literature/Schematics (3) Machine Age to Jet Age II, Stein 97 (page 243.)
Literature/Schematics (4) Cathedral & Tombstone Radios; Stein, 2008 (page 221.)
