• Year
  • 1968/1969
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 90321
    • alternative name: Fernsehgerätewerk Staßfurt

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 13
  • Number of Transistors
  • 1
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 3 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Ines 1001ST - Stern-Radio Staßfurt, VEB, RFT
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • VHF-Bereich Band I/III
    47cm Bildröhre, implosionsgeschützt.

    Siehe auch Modell Ines 1001STU mit UHF.

  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Andreas Hahn. See "Data change" for further contributors.
